The XTM 211Di MIG Inverter has 4 different processes available to the user making it ideal for the welding of Steels, Stainless Steels and Aluminium using the MIG, AC TIG, DC TIG or MMA processes. The machine uses auto polarity switching so there is no need to change the work lead connections on the front of the machine. Instant swapping between the MIG and TIG processes with one touch of the torch trigger makes it well suited to pipe applications or multi process workshops. The multi-language digital user interface rapidly gets you to the correct machine setting with minimal process knowledge, on site or in the workshop.
Key Features Include:
**PLEASE NOTE – The TR007 Trolley is only compatible with Serial Numbers 2007 or Higher**
Weight | 27.8 kg |
---|---|
Dimensions | 615 × 275 × 495 mm |
Phase |
Single Phase |
Machine Style |
Compact, Portable |
Machine Type |
Inverter |
Maximum Current |
140A DC, 200A DC |
Duty Cycle |
200A @ 25% Duty Cycle |
Input Voltage |
110V 1P, 230V 1P, Dual Voltage, Smart Switching |
Voltage |
110-200V (MMA), 140-200V (MIG), 140-200V (TIG) |
Feed Box |
2 Roll Drive |
Input Current (Eff) |
MIG – 21.4A @ 110V / 15A @ 230V, TIG – 20.5 @110V / 11.3A @ 230V, MMA – 20.6 @110V / 15.4A @ 230V |
Output |
DC |
Wire Size |
0.6-1.0mm |
Spool Size |
200mm (5kg), 300mm (15kg) |
Minimum Fuse Rating |
16A, 32A |
KVA |
7.8 |
Generator Size (Requires AVC) |
10 KVA |
Enclosure Protection |
IP23S |
Cooling |
Air, Fan, Forced |
Comes With |
3m Earth Cable, 3m Input Cable, CKE MMA Lead, Digital User Interface, Downloadable Mobile Application Option for Remote Mobile/Tablet Device Operation, Gas Hose, Multi-Language Functions |
Special Features |
Digital User Interface, Pulse TIG function for superior arc control, Smart Switching Dual Voltage, Synergic Control, Synergic Welding Rapid Set Up |
Warranty |
5 Year Warranty |
Conforms To |
IP23S, ISO/IEC 60974-1, ISO/IEC 60974-6 & RoHS compliant |
